W-EDM

• Machine Type : CNC
• Max. Job Size : 620 mm * 420 mm * 300 mm
• Machine Application : Wire Cutting (Submerged Type)

Co-Ordinate Measuring Machine (CMM)

• Make : Accurate
• Accuracy : ±2.9 + (L/300)µm
• Model : Cordimesur
• Max. Job Size : X 1000mm * Y 1800mm * Z 800mm

FTIR Spectroscope

• Make : ThermoElectron, USA
• Model : Nicolet 380
• Polymer & Plasticizer Library – 01 No
• Rubber Compounding Library
• Hummel Polymer Library – 01 No
• Lubrication Oil Library – 01 No
• Test Standard : ASTM E 1252

Multi Head Micro Hardness Tester

• Make: Gibitre. Itly
• Model : Multi Unit Hardness Tester
• IRHD : Normal & Micro Shore A & D
• In Compliance with : ISO 43-1987, ISO 868, BS 903, ASTM D 1415, ASTM D 2240

Differential Scanning Calorimeter (DSC)

• Model : DSC 60
• Make : Shimatzu, Japan
• Temp Range : Room Temp to 6000C
• Measuring Range :±40 mW
• Atmosphere : Air, Insert Gas (N2)
• Resolution : 1mW
• Test Standard : ASTM E928, ASTM D 1525, ASTM D 648

Melt Flow Indexer

• Make : Tinius Olsen, UK
• Model : MP 600
• Temp Range : Room Temp to 4500C
• Test Standards : ASTM D 1238 ISO 1133

Heat Deflection Temperature (HDT) & VICAT Softening Temperature Tester

• Make : Ceast, Spa, Itly
• Model : HDT 3 Vicat
• Microprocessor Control
• 3 Independent Work Stations for Three Simultaneous Tests
• Temp Range : Room Temp. to 3000C, Weight Range 1 to 5140 gm
• Test Standard : ASTM D 648 and ASTM D 1525

Accelerated Weathering Tester

• Make : Q Lab, USA
• Model : QUV / Spray
• Feature : Solar Eye Irradiance Control
• Chamber Size : 75 mm * 150 mm * 6 mm
• Lamp : UVB 313 EL
• Max Sample Capacity : 24 Nos
• Test Standard : ASTM & SAE Std.
• Fault Recognition : Alarms

Impact Tester

• Make : Ceast, Spa, Itly
• Model : Resil Impactor
• For Izod, Charpy & Tensile Impact text, resilience test (Notch and w/c Notch)
• Microprocessor Controlled
• Hammer Range : 1to 25 Joules for Izod, 4 J to 25 J
• Test Standard : ISO 180, 179

Ozone Test

• Make : In USA Inc, India
• Temp Range : Room Temp to 1000C
• Gas Phase : 0 to 9999
• Measuring Range : 0 to 200 PPHM Multiple Range
• Model : In 2000 – L2 – Low Concentration
• Chamber Size : 500 mm * 500 mm * 600 mm
• Test Standard : ASTM D1171, ASTM D1149
• Measuring Range : 0 to 200 PPHM Multiple Ranges

Xenon Test Chamber

Instron Actuator

Thermo Gravimetric Analyser (TGA)

• Make : Shimatzu, Japan
• Resolution : 1 µ
• Atmosphere : Air, Oxygen and Nitrogen
• Measuring Range : ± 200 µ

Universal Testing Machine (UTM)

• Make : Tinius Olsen, UK
• Capacity : 100 N to 23 Tons
• Cross Head Travel Excluding Grips : 1100 M
• Horizontal Clearance : 405 mm
• Speed Range : 0.001 mm/min to 1000 mm/min
• Speed At Max Capacity : 1000 mm/min
• Test Standards : ASTM D 683, ASTM D 412, ISO 178

Salt Spray Test Chamber

Dust Spray Test chamber

Water spray test chamber

Thermal shock test chamber

High Low-Test Chamber

SLS – EOS P385

• Platform : 320 mm * 320 mm * 520 mm
• Material : PA

RPT Machine Suitable for Proto Parts Development

• Engineering Functional Parts
• Automotive Parts
• Medical Application – Skull, Knee cap
• Architectural Models
• Styling Models

Vacuum Casting – KLM

• Dimensions : 360 x 400 x 460 mm

Materials

• Renishaw (Flexible Rubber)50 ~ 90 Shore hardness & wide range of Renishaw material
• Aerospace
• Research
• Medical

FDM – Stratasys 450 MC

• Platform Size : (406 x 355 x 406 mm)
• Materials : ABS-ESD / ABS-M30 / ABS-M30i / ASA

Specialized production parts in

• Automotive
• Aerospace
• Research
• Medical

SLA – 3D Systems 7000 HD

• Platform Size : 380 x 380 x 250 mm
• Materials : Accura Phoenix (SLA) / Visijet SL Flex

Specialized production parts in

• Automotive
• Aerospace
• Research
• Medical
• Investment casting Patterns

Deep Hole Drilling

• Make : Ixion
• Max. Job Size : 1.7 M * 0.4 M
• Machine Application : One Stroke 650 mm Deep Hole * ¢20

Deep Hole Drilling

• Machine Type : Z NC
• Max. Job Size : 2.5 M * 1.2 M/li>
• Machine Application : Die Sinking

Turn Mill Centre

• Make : ACE
• Max .Job Size : @ 250 * 600 mm
• Machine Application : Turining, Milling, Boring, Drilling, Reaming etc. with 12 Number Tool Turret

3+1 Axis VMC (Rotary Attachment)

• Make : TAI
• Max. Job Size : 1 M * 0.5 M * 0.65 M
• Max. Job Size : Machine Application : 2D – 3D Profile m/c, Boring, Drilling, Reaming etc. with 20 Number Tool ATC Capacity

5+1 Axis Laser (Rotary Attachment)

• Make : TRUMPF
• Max. Job Size : 3 M * 1.5 M * 0.75 M (4.5 KW)
• Machine Application : 2D – 3D Profile m/c, Oxygen Cutting up to 12 mm & Nitrogen Cutting up to 8 mm with Welding Head.

3-Axis VMC

• Make : Hartford
• Max. Job Size : 3 M * 1.4 M * 0.75 M
• Machine Application : 2D – 3D Profile m/c, Boring, Drilling, Reaming etc. with 16 Number tool ATC.

5-Axis VMC (Non-Continous)

• Make : Rambaudi
• Max. Job Size : 3 M * 2 M * 0.8 M
• Machine Application : 2D – 3D Profile m/c, Boring, Drilling, Reaming, Side face operations etc.
